TBM Consumables
Product Position:
Shield foaming agent is used for soil conditioning in EPB tunnelling. The foam solution (agent + water) is mixed with compressed air in a foam generator to produce fine, stable foam, which is injected at the cutterhead face and in the excavation chamber. The foam modifies soil properties — reducing internal friction angle, increasing plasticity, lowering permeability — making muck easier to discharge while reducing cutterhead torque and tool wear.
Shield foaming agent is used for soil conditioning in EPB tunnelling. The foam solution (agent + water) is mixed with compressed air in a foam generator to produce fine, stable foam, which is injected at the cutterhead face and in the excavation chamber. The foam modifies soil properties — reducing internal friction angle, increasing plasticity, lowering permeability — making muck easier to discharge while reducing cutterhead torque and tool wear.
HDC SF series uses biodegradable surfactants, glycol-free and environmentally friendly. Long foam half-life ensures the foam does not collapse from cutterhead cutting to screw conveyor discharge. Suitable for sand, clay, silt and mixed ground conditions.
|
Model |
Packaging |
Shelf Life |
Notes |
|
HDC-PMJ |
1000 kg IBC |
12 months |
|
|
Test Item |
Specification |
Test Method |
|
Appearance |
Light yellow transparent liquid |
Visual |
|
Density (20°C) |
1.00 – 1.05 g/cm³ |
GB/T 1884 |
|
pH Value |
7.0 – 9.0 |
GB/T 6368 |
|
Foam Expansion Ratio |
≥ 30 倍 (3% solution, 25°C) |
GB/T 11275 |
|
Foam Half-life |
≥ 30 min |
GB/T 11275 |
|
Water Solubility |
Fully soluble, high hydrophilicity |
Visual |
|
Recommended Dosage |
1% – 5% (vol. ratio) |
— |
• High foaming efficiency
Expansion ratio ≥30x
• Long-lasting foam
Half-life ≥30 min
• Significant torque reduction
Reduce cutterhead torque by 20–40%
• Eco-friendly & safe
Biodegradable ≥80%, glycol-free
• Wide applicability
Suitable for sand, clay, silt, mixed ground
• Synergy with dispersant
Use with SD series for anti-clogging + conditioning
Foam agent is used via the TBM foam generation system. Add concentrate to the foam tank at the recommended concentration, mix with water, pump to the foam generator where it is mixed with compressed air to form foam, then inject through pipelines to the cutterhead face and excavation chamber.
|
Ground Type |
Concentration |
Injection Ratio |
Gas/Liquid |
|
Sand |
3% – 5% |
30% – 50% |
6:1 – 10:1 |
|
Clay |
1% – 3% |
20% – 40% |
4:1 – 8:1 |
|
Silt |
2% – 4% |
25% – 45% |
5:1 – 10:1 |
|
Mixed |
3% – 5% |
30% – 50% |
6:1 – 10:1 |
